| Place of Origin: | Weifang |
| Brand Name: | QUALITY |
| Certification: | CE,ISO |
| Model Number: | HEYA-B |
| Minimum Order Quantity: | 4 UNITS Container house |
|---|---|
| Price: | Negotiation |
| Packaging Details: | SOC or In bulk |
| Delivery Time: | 7 days |
| Payment Terms: | T/T OR L/C |
| Supply Ability: | 100 Units container house |
| Structure: | Steel Frame | Size: | 6055mmX2435mmX2896mm |
|---|---|---|---|
| Application: | Camp,etc. | Door: | Steel Door |
| Usage: | Living | Roof: | Sandwich Tile |
| Type: | Prefab | Wall: | EPS Sandwich Panel |
| Color: | Customized | Layout: | Customized |
| Characteristic: | Professional Design |
Dimension(mm)&Weight(kg) for steel container house
|
Type |
External | Internal | Weight (kg) | |||||
| Length | Width | Height (package) | Height (assembled) | Length | Width | Height | ||
| 20’ | 6055 | 2435 | 648/864 | 2591/2790 | 5860 | 2240 | 2500 | from 1850 |
Floor:
| Steel frame | - made from cold rolled, welded steel profiles, 4 mm thick |
| - 4 corner casts, welded | |
|
- 2 fork lift pockets (except 30’) - distance 1200mm (internal clearance of fork lift pockets: 240×80 mm) |
|
| - steel cross members, thickness=2mm | |
| Insulation | - 100 mm thick Rock Wool |
| Subfloor | - 0.5mm thick, galvanized steel sheet |
| Floor | - 18mm plywood board |
|
- 1.8mm PVC floor - flammability class B1 - hardly combustible - smoke density class Q1 - low smoke emission - wear resistance factor: T level |
Roof:
| Steel frame | - made from cold rolled, welded steel profiles, 3mm thick |
| - 4 corner casts, welded | |
| - steel cross members, thickness=2mm | |
| Roof cover |
- 0.5mm thick, galvanized steel sheet - 360 degree seaming at joint of roof panels |
| Insulation | - 100 mm thick Rock Wool |
| Ceiling |
- 10 mm chipboard (V 20), laminated on both sides, white - the chipboard complies with the emission value E1 |
| CEE connector | - sunken in frame on short end side |
Insulation for steel container house
| Rockwool | - density:120kg/m3 |
|
- flammability class A- non combustible - smoke density class Q1 - low smoke emission |
|
| - certificated: CE & GL | |
| EPS | - density:10kg/m3 |
|
- flammability class B1- non combustible - smoke density class Q1 - low smoke emission |
|
| - certificated: CE & GL |
Why choose Container House as camp ?
A, Pefabrication
Safety, quality control, fast delivery
1) production and field work carried out at the same time, shorten the construction period
2) production in a controlled environment plant
3) eliminates the adverse effects, such as: the outside world because of the weather delay time limit for a project
4) field interference is minimal, to improve the safety of the user and site owners
5) quick installation
B:Flexibility
Product standard, simple, easy to be adjusted according to customer requirements
1) infinite transverse connection, longitudinal layer is up to three
2) indoor layout design according to the customer requirements
3) project during use can flexibly adjust
4) outside the house beautiful degree can be customized according to customer demand
C:Energy saving and environmental protection
1) uphold environmental protection concept in the module housing design and choice of materials
2) product prefabricated ensures zero waste site
3) after the project, the module housing can be easily removed, to restore the original appearance of the site
4) because of the module housing can be reused in different projects for many times, thus realizing the sustainable development of the real business model
China Heya is the best Chinese prefabricated housing solution supplier.
Our products include prefabricated house,container house, mobile homes, villas, light steel structure. We have more 6 years experience in the industry, professional manufacture and procurement team, maintain long-term cooperative relationship with many well-known manufacturers.Already finish Germany Refugee container house project,Zimbabwe Prefabricated Classroom Project,South Africa Prefab House,Uruguay Prefab Villages House project,and so on.
Our company is committed to become your trusted partner, you focus on your area of expertise, let us help you deal with the temporary office and warehouse of a comprehensive solution.
OUR FACTORY
OUR CERTIFICATION
OUR CLIENTS
Usually One 40HQ container can load 180 sq meter.Standard protective export packing.
A. Professional design and engineering team: Full solution for steel structure design.
B. Procurement and Manufacture for all material for prefabricated building. We have a professional procurement team to make sure all the materials are with good quality. And our factory operation under ISO/CE/SGS standard, to make sure the fabrication works with high technology.
C.Site management & Installation supervision, We could send our engineers to help for the installation supervision, you just need to prepare a team which know normal construction works will be O.K.
1, What's your Payment term?
50% deposit by TT, 50% balance before loading container by TT; 100% LC at sight(total payment over 100,000USD);
2, How about Shipping?
We use 40HQ container to ship the goods; Usually 40HQ container can load about 160-180 square meters house.
3, Delivery time?
Depend on MOQ,usually we can arrange shipment around 10days after received deposit
4, How to install?
Usually we will provide installation drawing,and if necessary,we also provide installation video.
5, Can you send workers to help me build house?
Considering the labor cost, safety and visa issues, we suggest to send one or two engineers to guide and train your staffs.
You must provide air tickets, hotel, and meal, and 100USD per day for engineer salary.
