To provide prefabricated housing solution services for customers,to innovate for customers' interests,to create value for customers.
Committed to create high quality items for shareholders,customers,employees and society.
 |
| Place of Origin: | Shandong ,China |
| Brand Name: | QUALITY |
| Certification: | CE Certification |
| Model Number: | HeYa-B |
| Minimum Order Quantity: | 4 sets |
|---|---|
| Price: | US $2,500 - 4,500 / Set |
| Packaging Details: | 1, Delivery by 40'HQ shipping container. 2, 4 in 1 flat packing |
| Delivery Time: | Shipped in 7 days after payment |
| Payment Terms: | L/C, T/T |
| Supply Ability: | 200 Set/Sets per Month |
| Key Words: | Ready Made Container House | Product: | Prefabricated Container Home |
|---|---|---|---|
| Product Name: | Tiny House Kits Container Prefabricated Flat Pack Office For Sale | Color: | White , Blue , Yellow , Gray , Customized |
| Structure: | Steel Frame Structure | Application: | House , Camp , Office , Villa , Hotel , Dorm , Others |
| Size: | 6055x2435x2896mm/6055x2435x2896mm | Certification: | ISO , CE Certification |
Our company is committed to become your trusted partner, you focus on your area of expertise, let us help you deal with the temporary office and warehouse of a comprehensive solution. Depending on your requirements, our engineers will provide you with the planning and design layout, professional installation and assembly team, will be completed in time for you to install. Rely on global supply chain procurement, to provide you with office furniture, air conditioning and other rich ancillary products.
Dimension(mm)&Weight(kg) for steel container house
|
Type |
External | Internal | Weight (kg) | |||||
| Length | Width | Height (package) | Height (assembled) | Length | Width | Height | ||
| 20’ | 6055 | 2435 | 648/864 | 2591/2790 | 5860 | 2240 | 2500 | from 1850 |
Floor of for steel container house
| Steel frame | - made from cold rolled, welded steel profiles, 4 mm thick |
| - 4 corner casts, welded | |
|
- 2 fork lift pockets (except 30’) - distance 1200mm (internal clearance of fork lift pockets: 240×80 mm) |
|
| - steel cross members, thickness=2mm | |
| Insulation | - 100 mm thick Rock Wool |
| Subfloor | - 0.5mm thick, galvanized steel sheet |
| Floor | - 18mm plywood board |
|
- 1.8mm PVC floor - flammability class B1 - hardly combustible - smoke density class Q1 - low smoke emission - wear resistance factor: T level |
Roof of steel container house
| Steel frame | - made from cold rolled, welded steel profiles, 3mm thick |
| - 4 corner casts, welded | |
| - steel cross members, thickness=2mm | |
| Roof cover |
- 0.5mm thick, galvanized steel sheet - 360 degree seaming at joint of roof panels |
| Insulation | - 100 mm thick Rock Wool |
| Ceiling |
- 10 mm chipboard (V 20), laminated on both sides, white - the chipboard complies with the emission value E1 |
| CEE connector | - sunken in frame on short end side |
Insulation for steel container house
| Rockwool | - density:120kg/m3 |
|
- flammability class A- non combustible - smoke density class Q1 - low smoke emission |
|
| - certificated: CE & GL | |
| NeoporR | - density:18kg/m3 |
|
- flammability class B1- non combustible - smoke density class Q1 - low smoke emission |
|
| - certificated: CE & GL |
Coatings (Optional)
| Deco Coating | Special coating can be applied on top of sandwich wall panel and make the external wall surface looks like plastering finishes or timber finishes. That makes the container house cozy and less industry look. |
From our factory to overseas client, there are two ways to delivery the houses. If your port can accept SOC (Shipper’s Owned Container), 4 standard cabins can be packed as a 20ft container and shipped naked. If can not, 7standard cabins can be loaded into one 40ft HC.
From the dealer’s workshop to the client’s place, it can be delivered by 6m long truck after assembly. The width and height are within traffic limitation.
Why choose container housing as camp ?
A, prefabrication
Safety, quality control, fast delivery
1) production and field work carried out at the same time, shorten the construction period
2) production in a controlled environment plant
3) eliminates the adverse effects, such as: the outside world because of the weather delay time limit for a project
4) field interference is minimal, to improve the safety of the user and site owners
5) quick installation
Two, flexibility
Product standard, simple, easy to be adjusted according to customer requirements
1) infinite transverse connection, longitudinal layer is up to three
2) indoor layout design according to the customer requirements
3) project during use can flexibly adjust
4) outside the house beautiful degree can be customized according to customer demand
Three, energy saving and environmental protection
1) uphold environmental protection concept in the module housing design and choice of materials
2) product prefabricated ensures zero waste site ""
3) after the project, the module housing can be easily removed, to restore the original appearance of the site
4) because of the module housing can be reused in different projects for many times, thus realizing the sustainable development of the real business model
